carbon fabric, carbon fibre 24K t700, carbon fabric ud
TECHNICAL CHARACTERISTICS
Areal weight: 150 g / m2
Weaving style: Unidirectional
Width: 1.00 meter
Warp: 24K T700 carbon fiber 100%
Weft: No weft (warp fibers are held in place by thermaly stabilized pol./glass yarn)
Weaving style: Unidirectional
Width: 1.00 meter
Warp: 24K T700 carbon fiber 100%
Weft: No weft (warp fibers are held in place by thermaly stabilized pol./glass yarn)
TYPICAL MECHANICAL PROPERTIES OF 24K T700 CARBON FIBER
Tensile strength (MPa): 4900
Tensile modulus (GPa): 230
Elongation at break (%): 2.1
